Pre-Made Pouch Fillers
Spining Accent Triangle

Triangle/JDD Pre-Made Pouch Fillers

Our pre-made pouch fillers is an ideal solution for food packagers and others looking for an automated method to fill and seal pre-made pouches. The rotary pouch filler is designed to fill and seal Doy bags, 3-sided seal, flat and Stand-Up Pouches (SUP), as well as zippered bags, at speeds up to 50 pouches per minute.

The rotary pouch filler is ideal for a variety of markets, including: granola, snacks, confectionery, popcorn, dried fruit, nuts, powders and baking mixes, beef jerky and more.

triangle
pre-made-pouch-feat-ben

Features and Benefits

  • Auto stop to fill. Bags not opened will not be filled, which saves wasted product. No fill, no seal feature allows unopened bags to be reused.
  • Quick, easy tool-less changeover
  • Store up to 48 different recipes in the HMI
  • Handles various film structures, including foil
  • Stainless steel frame (painted cast frame enclosed)
  • Horizontal infeed belt to handle all pouch styles
  • Date coder included
  • Top and bottom pouch opening with air assist
  • Pouch shaker to assist with product settling
  • Two sealing stations
  • Pouch outfeed conveyor

Optional Features

  • Nitrogen gas flush
  • Staging gate
  • Data backup on flash card ethernet
  • Turnkey integration
pre-made-pouch-op-feat
triangle

Pre-Made Pouch Fillers Specifications

Max Speed Up to 50 pouches/min
Min/Max Pouch Width 4" to 12"
Min/Max Pouch Height 4" to 15"
Footprint 76"W x 123"D
PLC Rockwell
Connection Ethernet
triangle
