X-Series Continuous Motion VFFS
Spining Accent Triangle

Sanitary Continuous Motion VFFS

X-Series continuous motion vertical form fill seal baggers increase production yield while enhancing food safety efforts. Built and serviced in the USA at our Chicago, IL facility and designed for 24/7 operation, X-Series baggers are rugged and run in even the harshest environments. With 360° machine access, maintenance and cleaning are made simple. This all-servo bagger offers faster operating speeds, helping end users achieve speeds up to 150 bags per minute.

x-series VFFS hero new
x-series-sanitary-

Sanitary VFFS Machines Enhance Food Safety

X-Series VFFS bag machines are designed and built with the strictest sanitary requirements in mind. Available in four sanitation levels, including painted steel, stainless steel, stainless steel washdown and USDA/3-A. Sanitary features include:

  • Sloped control box which pivots to provide 360º of machine access
  • Continuously welded tubular frame; solid frame optional
  • Servo motors available in three sanitation levels
  • Open cable management
  • Quick removal of sealing jaws and back seal components for easy washdown
  • Cross members rotated 45º to allow product runoff

Quick Changeover with Centerline Design

Changeover is simplified with a centerline design that allows for quick change of film in less than two minutes. Change parts can be either color-coded or alphanumeric. Tool-less, quick change parts that reduce downtime include:

  • 16-sided forming tubes
  • Film rolls
  • Vertical back seals
  • Sealing jaws
delta-changeover
triangle

X-Series VFFS Specifications

Designed to easily integrate into your new or existing line, the X-Series VFFS bagger provides high-speed, sanitary forming, filling and sealing.

X-Series Specifications:
  Standard
Max Speed Up to 150/min
Max Bag Width 15"
Footprint  68"W x 80"D
Control Box  NEMA 4X
Rating  IP67 Servos
PLC Rockwell
Connection Ethernet
Sealing Options Heat or Ultrasonic



triangle

X-Series VFFS Bagger Options

Ultrasonic or heat sealing.

Ultrasonic or Heat Sealing

Choose between ultrasonic or heat sealing based on application for complete versatility.

Integrated zipper applicator.

Integrated Zipper Applicator

Easily fill zipper bags that fully open from left to right, allowing for easy product access.

Liquid squeegee design to keep liquid out of the sealing area.

Liquid Squeegee

Achieve clean seals every time with unique squeegee design that keeps liquid out of the sealing area.

Delta-mult-bag-styles-feat-cardArtboard 1

Multiple Bag Styles

Easily run multiple bag styles, including EZ-stand, pillow bags, gusseted and flat bottom bags.

Rotatable jaws that require no heavy equipment.

Rotatable Jaws

Simply switch formats in 10 minutes or less with easy-to-rotate jaws that require no heavy equipment or complicated tools.
